What Are Pallet Collars Used For?
Pallet collars are a practical solution used in logistics and warehousing that enhance the functionality of standard pallets. They are used to create temporary crates or containers on pallets, allowing for the safe storage and transport of products of various shapes and sizes. Pallet collars protect goods from damage, prevent them from shifting during transport, and help organize warehouse space. Additionally, their easy disassembly makes them an economical and flexible solution that can be adapted to current logistical needs.
Our Machine Offer
- Cycle time: 6.3 seconds
- Production rate: 3,500 units per shift (8 hours)
*This is the average cycle time calculated based on experience. Changing the operator during their break or having a second operator assist can result in higher production output. Production efficiency may be affected by the type of hinges or boards used. - Collar production capability: 800×1200 mm.
- Number of operators required: 1 operator
- Extended rivet head lifespan. Durability of the head: 1 million cycles. Approximately 1 year of operation. Annual maintenance involves bearing replacement.
- Cycle time: Machine cycle time = approximately 2 seconds.
Loading and unloading time by the operator is estimated at around 20 seconds. The time depends on the operator and the organization of their workspace. - Maximum production capacity: 800 collars per 8-hour shift.
- Collar production capability: 800×1200 mm.
- Pin magazine on each station: Approximately 1000 pins per station.
Machine best suited for pallet collars with large, non-standard dimensions that are not compatible with automated systems.
Maximum performance capacity: up to 1300 collars per 8-hour shift.
Capable of producing pallet collars in any dimension.
Machines currently under design
N2V3 Hinge Riveting Machine for Boards
We are currently working on a new machine, which is in the advanced design phase. Our engineering team is making every effort to significantly increase its efficiency, allowing our clients to achieve even better results.
- Cycle time: 4 seconds
- Production rate: 5,000 units per shift (8 hours)
Estimated machine cycle time. - Board production capability: from 600 to 1600 mm
- Number of operators required: 1 operator
- Two movable sides of the machine: Allows the riveted boards to always be centered on the machine.
- Reinforced mechanisms: These will allow for longer, maintenance-free operation of the machine.
